Airbag Berry Juice Extractor（juicer）
Airbag berry juice extractor（juicer） is mainly used for the juicing of fruit pulp after fruit crushing, and is suitable for the juicing of berry fruits.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Device description
Airbag berry juice extractor(juicer) mainly used for berry fruit juice, can be equipped with inert gas protection device, pressure process completely isolated from oxygen, eliminate oxidation, is to obtain high-quality juice equipment.
The main part of airbag berry juice extractor(juicer) is made of 304 stainless steel, and the whole machine can be controlled by PLC intelligent control system to realize the free switching of automatic and manual modes.
Working principle
Airbag berry juice extractor(juicer) is equipped with a tubular air bag made of advanced non-toxic materials, which is mounted on a bracket and is fixed on a stainless steel roller with holes; The roller is the whole hole, which is doubled compared with the ordinary juicing area. When juicing, the air bag expands and fills the entire surface. Because the juicing area is doubled compared with the usual juicer, the juicing time can be greatly shortened, and the working cycle and pressure can be reduced; The product is divided into pancake layers, and the juice oozes from the entire surface of the sieve cylinder (360 degrees). Based on the above equipment characteristics, the product quality is greatly improved, the material can not be moved for a long time during the pressing process, the pressure is 1.5 bar, only a short time at the end of the production, and airbag berry juice extractor(juicer) is equipped with a separate compressed air system.
Technical parameter
| Product name | Airbag berry juice extractor(juicer) |
| Equipment type | JPAE-100 |
| Main material | Food grade SUS304 Quality stainless steel (or customized according to customer requirements) |
| Processing capacity | 0.5 tons/hour to 30 tons/hour (or customized according to customer requirements) |
| Size specification | 2250*800*900 to 6500*900*1600(mm) |
| Equipment application | Airbag berry juice extractor(juicer) is suitable for berry fruit juice |
| Scope of application | Apple, pear, grape, pomegranate and other fruit and vegetable raw materials |
Products Description
- All working procedures are controlled by PLC and can be adjusted according to the condition of raw materials.
- Under the press there is a slag collection tank. Once the juice is finished, the residue can be discharged; Because it is not an internal slag discharge design, it will not be clogged frequently, and cleaning becomes easier.
- Equipped with special injection piping system and wide cleaning port.
