Garlic Processing Line

End product

Garlic sauce, garlic powder, garlic oil etc

Processing capacity

From 5 T/day to 100 T/day, or customized

Juice Efficient input

90% raw fruit (10% as waste, peels)

Main processing flow

Garlic peeling, crushing, dehydration, mixing and packing

End product package

In drum can, glass bottle, PET bottle or plastic bags etc.

Output

Can be calculated

Budget range

Customized from 20000USD to 2000000USD, please reach us

for tailored solution

1. garlic pre-treatment machines:

garlic peeling machine

It adopts a pneumatic principle, which will not damage the garlic after peeling the skin. Garlic Peeling Machine can peel the garlic skin completely in a dry way, so there is no need to put the garlic in the water before peeling.

Garlic splitting machine

The garlic breaking separating machine is designed to separate the garlic bulbs into garlic cloves. It is equipped with standard rubber rollers, so the machine won’t damage the garlic during the garlic bulb separation process.

Air-blowing washing machine

Special design of surfing and bubbling to ensure a thorough cleaning and lessening the damage to the material as well.

2.garlic sauce processing machines

garlic crushing machine

The washed garlics are chopped before going to the treatment line. The chopping dimensions depend on the required extraction.

Pre-heater and enzyme deactivation machine

Used for deactivating enzyme and pasteurizing of crushed products and  softening the fibers and to get consequently the maximum juice yield..;Adjustable temperature control and automatic return flow function.

Garlic milling machine

The colloid mill is a type of rotor-stator mixer often used in the manufacturing of emulsion and dispersion. It can also be used to reduce the particle size of solids in suspension. It is commonly used in food industry, such as making peanut butter, sesame butter and other nut butter.Also it can use to grinding milk, vegetable and fruit jam.It is a good performance grinding machine.

3.Dehydrated garlic processing machines:

garlic slicer

To slice or dice the garlic into different dimensions. The machine has complete with set of various blades for long slice, round slice,cubes and strips

garlic drying machine

Including accessories(movable carts and trays)and inbuilt temperature regulator and control cabinets

Variable drying temp: 55-85℃ (adjustable)

Capacity: 1ton-5ton per batch

Material: Stainless steel (food contact part) SS 304

Grinding machine for garlic powder

Material enters the mill chamber via screw conveyor where it is sheared and milled by  fast-rotating blades. The powder passes the guide ring and enters the classifier chamber. As the classification wheel is in rotation, both  air force and centrifugal force act on the powder. As the particles whose diameters are greater than the critical diameter (diameter of the classification particles) have a greater mass, they are thrown back into the mill chamber to be ground again, while the particles whose diameters are smaller than the critical diameter enter  cyclone separator and dust-collecting box.
