Pineapple Processing Line



Pineapple is one of the most popular tropical fruit and the consumption of its delicious juice is increasing significantly. We has developed highly specialized technologies for the production of both natural and concentrated pineapple juice.We design, manufacture and supply complete Pineapple Processing Line, We are especially proud of our dedicated pineapple juice/puree/pulp production line, which guarantees utmost product quality by minimizing any contact between peel and juice.



Raw material	Fresh Pineapple
End product	Pineapple Puree or concentrate, smoothie
Processing capacity	From 20T/day to 1500T/day
Juice Efhcient input	85% raw fruit (15% as waste),depends on different variety
End product package	Aseptic Bag, Bottle, Tin Cans, Pouch, Pet, etc
Automatic level	High Automatic or as per customer's requirements
Equipment Material:	Food grade SUS 304 or SUS 316 stainless steel









Turnkey solution fruit juice and fruit paste/puree processing line

1).Receiving system

2).Washing system

3).Elevating system

4).Sorting system.

5.)Curshing section

6).Preheating system

7).Pulping & Refining

8.)Sterilizting section

9) Vaccum evaporating

10.)Filling system.

11)Post sterilization









1).Bucket Elevator	1. Smooth bucket structure against clamping fruits, suitable for tomato, strawberry, apple, pear, apricot, etc. 2. Running stably with low noise, speed adjustable by transducer. 3. Anticorrosive bearings, double sides seal.
2).Air Blowing & Washing Machine	1 Used to wash fresh tomato, strawberry, mango, etc. 2 Special design of surfing and bubbling to ensure a through cleaning and lessening the damage to the fruit as well. 3 Suitable for many kinds of fruit or vegetables, such as tomatoes, strawberry, apple,mango,etc.
3.)Peeling, pulping & Refining Monobloc (Pulper)	1. The unit can peel, pulp and refine fruits together. 2. The aperture of strainer screen can be adjustable (change) based on customer's requirement. 3. Incorporated Italian technology, high quality stainless steel material in contact with fruit material.
4.)Belt press extractor	1. Widely used in extracting and dehydrating of many kinds of acinus, pip fruits, and vegetables. 2. the unit adopt advanced technology, big press and high efficiency, high degree of automatic, easy to operate and maintains. 3. the extraction rate can be get 75-85%(based on raw material) 4. low investment and high efficiency
5.)Preheater	1. To inactivate enzyme and protect color of paste. 2. Auto temperature control and the out temperature are adjustable. 3. Multi-tubular structure with end cover 4. If the effect of preheat and extinguish enzyme failed or not enough, the product flow return to tube again automatically.
6.)Evaporator	1. Adjustable and contrllable direct contact heat treatment units. 2. Shortest possible residence time, presence of a thin film along the entire length of the tubes reduces holdup and residence time. 3. Special design of liquid distribution systems to ensure correct tube coverage. The feed enters at the top of the calandria where a distributor ensures film formation on the inside surface of each tube. 4. The vapor flow is co-current to the liquid and the vapor drag improves the heat transfer. The vapor and the remaining liquid are separated in a cyclone separator. 5. Efficient design of separators. 6. Multiple effect arrangement provides steam economy.
7.)Tube in tube sterilizer	1. The united is consisted of product receiving tank, superheated water tank, pumps, product dual filter, tubular superheated water generate system, tube in tube heat exchanger, PLC control system, Control cabinet, steam inlet system, valves and sensors, etc. 2. Incorporated Italian technology and conform to Euro-standard 3. Great heat exchange area, low energy consumption and easy maintenance 4. Adopt mirror welding tech and keep the smooth pipe joint 5. Auto backtrack if not enough sterilization 6. CIP and auto SIP available together with aseptic filler 7. Liquid level and temp controlled on real time







SH JUMP'S Pineapple Processing Line and Pineapple Puree Making Equipment are fully automatic machine;

Also can do customize to meet all clients requests.We design, manufacture and supply complete Pineapple Production Processing Line
